18. Troubleshooting
Fault description
Possible fault cause
Required measures
Heating
Set-point temperature is not
reached after specified time.
Chamber door not properly
closed.
Completely close chamber door.
Door gasket defective.
Replace door gasket,
Controller not adjusted.
Calibrate and adjust controller.
Chamber heating permanently,
set-point not held.
Controller defective.
Contact BINDER service.
Pt 100 sensor defective.
Semiconductor relay defective
Controller not adjusted.
Calibrate and adjust controller.
Chamber doesn’t heat up.
LED (3a) “Heating active” lit.
Heating element defective.
Contact BINDER service.
Semiconductor relay defective.
Chamber doesn’t heat up.
LED (3a) “Heating active” not lit.
Controller display working.
Semiconductor relay defective.
Contact BINDER service.
Controller defective.
Chamber permanently turned
off.
Red indicator lamp of safety
device class 2 (2a) lit.
Safety device class 2 has turned
off the oven.
Let cool down the oven and press
down RESET button. Check
temperature set-point and setting of
safety device (chap. 14.1). If
appropriate, select suitable limit
value.
Safety device class 2 defective.
Contact BINDER service.
Chamber permanently turned
off.
No power supply.
Check connection to power supply.
Wrong voltage.
Check power supply for voltage of
115V or 230V.
Chamber fuse has responded.
Check chamber fuse and replace it
if appropriate. if it responds again,
contact BINDER service.
Controller defective.
Contact BINDER service.
Deviations from the indicated
heating-up times.
Oven fully loaded.
Charge the oven less or consider
longer heating-up times.
Controller
Program duration longer than
programmed.
Inappropriate tolerances have
been programmed.
For rapid transition phases, do
NOT program tolerance limits in
order to allow maximum heating
speed.
Program stops one section too
early.
Program line is incomplete.
When programming, define the end
value of the desired cycle by
adding an additional section with a
section time of at least one minute.
Programs have been deleted.
Change from 2 programs to 1
program or vice-versa
When changing, ensure that the
programs are no more needed.
The controller returns to Normal
Display from any level.
No button was hit for more than
120 sec.
Repeat entries, enter the values
rapidly.
Message RANGE ERROR CH1
in Normal Display in Display 2
Sensor rupture between sensor
and controller
Contact BINDER service.
Ramp temperature transitions
are only realized as steps.
Set-point programming type set
to “Step” in the User level (chap.
10).
Set the set-point programming type
to setting “Ramp” in the User level
(chap. 10).
Have repairs performed only by experts authorized by BINDER. Repaired chambers must
comply with the quality standard specified by BINDER.
