Figure 4: Chamber overview, open chamber with glass door (BD-S / BD-S-UL)
(1) Triangular instrument panel with R-S controller
(2) Outer door
(2a) Outer door handle
(3) Exhaust air outlet
(3a) Exhaust air flap
(4) Glass door (BD-S / BD-S-UL)
(4a) Glass door handle (BD-S / BD-S-UL)
(5) Rack
(5a) Rack support
2.2 Triangular instrument panel
Figure 5: Triangular instrument panel with R-S controller
(6) Controller display
(7) Functional controller buttons
(4a)
(2)
(5)
(4)
(1)
(2a)
(5a)
(7)
(6)
(7)
