4.3 Electrical connection
The chambers are supplied ready for connection and come with an IEC connector plug.
Model Model version
Power plug of
power cable
Nominal voltage +/- 10% at
the indicated power fre-
quency
Current
type
Cham-
ber fuse
BD-S 56 BD-S056-230V Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
ED-S 56
FD-S 56
ED-S056-230V
FD-S056-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
BD-S 115 BD-S115-230V Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
ED-S 115
FD-S 115
ED-S115-230V
FD-S115-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
BD-S-UL 56 BD-S056UL-120V
NEMA 5-
15P
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
ED-S-UL 56
FD-S-UL 56
ED-S056UL-120V
FD-S056UL-120V
NEMA 5-
15P
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
BD
-S-
UL 115
BD-S115UL-120V
NEMA 5-
15P
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
ED
-S-
UL 115
FD
-S-UL 115
ED-S115UL-
120V
FD-S115UL-120V
NEMA 5-
15P
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
• The domestic socket must also provide a protective conductor. Make sure that the connection of the
protective conductor of the domestic installations to the chamber’s protective conductor meets the latest
technology. The protective conductors of the socket and plug must be compatible!
DANGER
Electrical hazard due to missing protective conductor connection.
Deadly electric shock.
 Make sure that the chamber’s power plug and the power socket match and se-
curely connect the electrical protective conductors of the chamber and the house
installation.
• Only use original connection cables from BINDER according to the above specification.
UL chambers: Use only a UL Listed Power supply cord (UL category ELBZ). For outside USA use a
certified power supply cord according to national requirements.
• Prior to connection and start-up, check the power supply voltage. Compare the values to the specified
data located on the chamber’s type plate (left-hand side of the chamber, chap. 1.6).
NOTICE
Danger of incorrect power supply voltage due to improper connection.
Damage to the chamber.
 Check the power supply voltage before connection and start-up.
 Compare the power supply voltage with the data indicated on the type plate.
• When connecting, please observe the regulations specified by the local electricity supply company as
well as the local or national electrical regulations (VDE directives for Germany).
• Observe a sufficient current protection according to the number of devices that you want to operate. We
recommend the use of a residual current circuit breaker.
