Binder Solid.Line BD-S 56 - Technical data

BD-S / BD-S-UL, ED-S / ED-S-UL, FD-S / FD-S-UL (E1) 03/2022 page 35/60
14.4 Technical data
Model
BD-S
BD-S-UL
ED-S
ED-S-UL
FD-S
FD-S-UL
BD-S
BD-S-UL
ED-S
ED-S-UL
FD-S
FD-S-UL
Chamber size
56
56
56
115
115
115
Exterior dimensions
Width, net
mm /
inch
595 /
23.43
595 /
23.43
595 /
23.43
745 /
29.33
745 /
29.33
745 /
29.33
Height, gross (incl. feet)
mm /
inch
625 /
24.60
625 /
24.60
625 /
24.60
735 /
28.94
735 /
28.94
735 /
28.94
Depth, net
mm /
inch
525 /
20.67
525 /
20.67
525 /
20.67
565 /
22.24
565 /
22.24
565 /
22.24
Depth, gross (incl. door han-
dle)
mm /
inch
580 /
22.83
580 /
22.83
580 /
22.83
620 /
24.41
620 /
24.41
620 /
24.41
Wall clearance rear (minimum)
mm /
inch
160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30
Wall clearance side (minimum)
mm /
inch
100 / 3.94 100 / 3.94 100 / 3.94 100 / 3.94 100 / 3.94 100 / 3.94
Spacing above the chamber
mm /
inch
160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30 160 / 6.30
Exhaust air outlet, inner diame-
ter
mm /
inch
50 / 1.97 50 / 1.97 50 / 1.97 50 / 1.97 50 / 1.97 50 / 1.97
Doors
Number of doors
1
1
1
1
1
1
Number of inner glass doors
1
--
--
1
--
--
Interior dimensions
Width
mm /
inch
400 /
15.75
400 /
15.75
400 /
15.75
550 /
21.65
550 /
21.65
550 /
21.65
Height
mm /
inch
440 /
17.32
440 /
17.32
440 /
17.32
550 /
21.65
550 /
21.65
550 /
21.65
Depth
mm /
inch
350 /
13.78
350 /
13.78
310 /
12.20
390 /
15.35
390 /
15.35
350 /
13.78
Interior volume
l / cu.ft.
62 / 2.19
62 / 2.19
55 / 1.94
118 / 4.17
118 / 4.17
106 / 3.74
Steam space volume
l / cu.ft.
62 / 2.19
62 / 2.19
62 / 2.19
118 / 4.17
118 / 4.17
118 / 4.17
Racks
Quantity of racks (regular)
1
1
1
1
1
1
Quantity of racks (max.)
3
3
3
5
5
5
Max. load per rack
Kg / lbs
15 / 33
15 / 33
15 / 33
20 / 44
20 / 44
20 / 44
Permitted total load
Kg / lbs
45 / 99
45 / 99
45 / 99
75 / 165
75 / 165
75 / 165
Weight
Weight (empty)
Kg / lbs
35 / 77
36 / 79
35 / 77
47 / 104
50 / 110
48 / 106
Temperature data
Temperature
range
from … degrees
above ambient
°C / °F 5 / 9 7 / 12.6 14 / 25.2 5 / 9 7 / 12.6 14 / 25.2
up to
°C / °F
70 / 158
250 / 482
250 / 482
70 / 158
250 / 482
250 / 482
Temperature fluctuation at
37 °C / 98.6 °F
+/- K 0.3 -- -- 0.3 -- --
Temperature fluctuation at
50 °C / 122 °F
+/- K -- 0.3 -- -- 0.3 --
Temperature fluctuation at
150 °C / 302 °F
+/- K -- 0.7 0.4 -- 0.9 0.4
Temperature fluctuation at
250 °C / 482 °F
+/- K -- 1.3 -- -- 1.7 --
