Binder Solid.Line BD-S 56 - Page 36

BD-S / BD-S-UL, ED-S / ED-S-UL, FD-S / FD-S-UL (E1) 03/2022 page 36/60
Model
BD-S
BD-S-UL
ED-S
ED-S-UL
FD-S
FD-S-UL
BD-S
BD-S-UL
ED-S
ED-S-UL
FD-S
FD-S-UL
Chamber size
56
56
56
115
115
115
Temperature data (continued)
Temperature uniformity (varia-
tion) at 37 °C / 98.6 °F
+/- K 0.5 -- -- 0.6 -- --
Temperature uniformity (varia-
tion) at 150 °C / 302 °F
+/- K -- 3.4 2.6 -- 2.8 2.0
Heating up time to 150 °C /
302 °F
minutes
-- 60 15 -- 55 20
Heating up time to 250 °C /
482 °F
minutes
-- 75 -- -- 75 --
Recovery time after door was
opened for 30 sec at 37 °C /
98.6 °F
minutes
15 -- -- 15 -- --
Recovery time after door was
opened for 30 sec at 150 °C /
302 °F
minutes
-- 45 5 -- 40 8
Ventilation data
Air change
x/h
--
--
4
--
--
2
Electrical data (model versions BD-S056-230V, BD-S115-230V, ED-S056-230V, ED-S115-230V, FD-
S056-230V, FD-S115-230V)
System of housing protection
acc. to EN 60529
IP 20 20 20 20 20 20
Nominal voltage (+/-10%)
at 50 Hz power frequency
V 230 230 230 230 230 230
Nominal voltage (+/-10%)
at 60 Hz power frequency
V 230 230 230 230 230 230
Current type
1N~
1N~
1N~
1N~
1N~
1N~
Nominal power
kW
0,30
1,05
1,10
0,35
1,25
1,30
Power plug of the power cable
Grounded plug
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 6,3 6,3 6,3 6,3 6,3 6,3
Overtemperature protective
device class 1
°C
°F
90 /
194
318 /
604.4
318 /
604.4
90 /
194
318 /
604.4
318 /
604.4
Installation category acc. to
IEC 61010-1
II II II II II II
Pollution degree acc. to IEC
61010-1
2 2 2 2 2 2
Different electrical data for UL chambers constructed for the USA and Canada (model versions BD-
S056UL-120V, BD-S115UL-120V, ED-S056UL-120V, ED-S115UL-120V, FD-S056UL-120V, FD-
S115UL-120V)
Nominal voltage (+/-10%)
at 50 Hz power frequency
V 120 120 120 120 120 120
Nominal voltage (+/-10%)
at 60 Hz power frequency
V 120 120 120 120 120 120
Nominal power
kW
0,30
1,15
1,20
0,35
1,35
1,40
Power plug of the power cable
NEMA
5-15P
5-15P
5-15P
5-15P
5-15P
5-15P
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 12,5 12,5 12,5 12,5 12,5 12,5
Environment-specific data
Noise level (mean value)
dB (A)
--
--
43
--
--
43
Energy consumption at 37 °C /
98.6 °F
Wh/h 25 -- -- 30 -- --
Energy consumption at 150 °C
/ 302 °F
Wh/h -- 210 290 -- 300 340
