III. SPECIFICATIONS, CONNECTIONS & USER INTERFACE cont’d.
10
1010
10
B
BB
B-
--
- SPECIFICATIONS
SPECIFICATIONS SPECIFICATIONS
SPECIFICATIONS
Rate 5 – 150 bpm
Inspiratory Time 0.1 – 3 seconds
Tidal Volume 5 – 2500 ml
Flow Rate 1 – 120
Inspiratory Time 0.10 – 3.0 seconds
I:E Ratio 3:1 to 1:99
Peak Pressure 0 – 120 cmH
2
O
PEEP Pressure 0 - 35 cmH
2
O
Pressure Trigger -0.2 to –10 cmH
2
O
Pressure Support 0 – 50 cmH
2
O
SIMV Rate 0.6 – 50 bpm
Sigh 0 - 2500 ml
Maximum Safety Pressure: 120 cmH
2
O
Pneumatic Power Source: 31 to 75 psi (214 – 517 kPa)
1
Audible Alarm Characteristics: 90 dB at 10cm (25°C)
Electrical Power Source:
See Appendix F at the beginning of the manual
Output: 16.0 VDC, 3 A
Output Protection: Short Circuit and Overload
Isolation: Meets IEC601.1, classification BF, UL 544 Patient Care, CSA 125
Risk Class 2G
Maximum Ripple: <100 mVp-p
Safety: Approved to UL 544/2601.1, CLU (CSA) 22.1 #125/601.1, TUV
EN60601.1 & CE LVD
EMC: Designed to Level B Requirements of FCC part 15, CISPR11
(EN55011). Less than 1 Volt Output Deviation for IEC801-2, 3,
4, 5, Immunity Tests.
Overall Dimensions
Height: 10" (25.4 cm)
Width: 11" (28.0 cm)
2
Depth: 5.5" (14 cm)
Weight: 10.5 lbs. (4.8 kg)
3
Operating Temperature: 32° to 104° F. (0° to 40° C)
4
Storage Temperature: 32° to 122° F. (0° to 50° C)
4
1- If an air/oxygen blender is used, then 45 – 75 PSI (310 – 517 kPa) should be supplied to the blender.
2- 14.25” (36.2 cm) with optional mounted blender
3- 13.25 lbs. (6 kg) with optional mounted blender
4- When using the oxygen sensor, then 41° – 104° F (5° – 40° C); battery will not fast charge below 41° F (5° C) nor above
125° F (51° C).
