BIO-MED DEVICES CROSSVENT-3+ - Parts List and Schematic Diagrams; A- Replacement Parts List

68
6868
68
X. PARTS LIST AND SCHEMATIC DIAGRAMS
A
AA
A-
--
- REPLACEMENT PARTS LIST
REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST
REPLACEMENT PARTS LIST
NOTE: SERIAL NUMBER OF VENTILATOR MUST ACCOMPANY ALL PARTS ORDERS
ITEM PART # DESCRIPTION
1 PRT3348
KIT, PREVENTIVE MAINTENANCE (UNITS WITHOUT FLOW SENSOR
AND WITHOUT ENTRAINMENT)
2 PRT3350
KIT, PREVENTIVE MAINTENANCE (UNITS WITHOUT FLOW SENSOR
BUT WITH ENTRAINMENT)
3 PRT3353
KIT, PREVENTIVE MAINTENANCE (UNITS WITH FLOW SENSOR BUT
WITHOUT ENTRAINMENT)
4 PRT3354
KIT, PREVENTIVE MAINTENANCE (UNITS WITH FLOW SENSOR &
ENTRAINMENT)
6 PRT4467 BATTERY PACK, 6 D CELL NiMH (Do not substitute)
12 PRT3316 ASSY, LCD/TOUCHSCREEN DISPLAY
13 PRT4410 LED, ALARM
15 PRT3318 PC BOARD FOR UNITS WITH FLOW SENSOR- NO DISPLAY INCL’D*
15A PRT3319 PC BOARD FOR UNITS WITH FLOW SENSOR- DISPLAY INCL’D*
16 PRT3322 PC BOARD FOR UNITS WITHOUT FLOW SENSOR- NO DISPLAY INCL’D*
16A PRT3323 PC BOARD FOR UNITS WITHOUT FLOW SENSOR- DISPLAY INCL’D*
23 EVAL006 SOLENOID
29 4419A CHARGER w/US HOSPITAL-GRADE CORD (Do not substitute)
30 4419B CHARGER w/EURO UNTERMINATEDCORD (Do not substitute)
32 PFIL008 FILTER, CONICAL SUPPLY
141 PRT3317 PRESSURE SENSING SWITCH
