BIO-MED DEVICES CROSSVENT-3+ - Additional Alarms Outside of the Alarm Menus; Alarm 3

III. SPECIFICATIONS, CONNECTIONS & USER INTERFACE cont’d.
20
2020
20
ALARM PARAMETER RANG
ALARM PARAMETER RANGALARM PARAMETER RANG
ALARM PARAMETER RANGES AND ALARM LIMITS
ES AND ALARM LIMITSES AND ALARM LIMITS
ES AND ALARM LIMITS
SET LIMITS
PARAMETER DISPLAY RANGE
LOW HIGH
PEEP/CPAP cmH
2
O 0-99 -1 to 99 0-100
Mean Pressure cmH
2
O 0-125 0-124 1-125
O
2
0-100 18-100 19-105
ADDITIONAL ALARMS OU
ADDITIONAL ALARMS OUADDITIONAL ALARMS OU
ADDITIONAL ALARMS OUTSIDE OF THE ALA
TSIDE OF THE ALATSIDE OF THE ALA
TSIDE OF THE ALARM MENUS
RM MENUSRM MENUS
RM MENUS
CONDITION INDICATED BY FLASHING
1
INSPIRATORY < 0.1 SEC., > 3.0 SEC INSPIRATORY DISPLAY
EXPIRATORY < 0.2 SEC. EXPIRATORY DISPLAY
I/E > 3:1 or > 1:99 I/E DISPLAY
T
I
+ FLOW = TV >2500 ml TV DISPLAY
NO EXTERNAL POWER BATTERY KEY
LOSS OF POWER LED
MICROPROCESSOR COMMUNICATION ERROR
2
LED
1
audible alarm accompanies any flashing alarm
2
see Appendix E for beeper codes
ALARM 3
ALARM 3ALARM 3
ALARM 3
This menu displays the conditions shown in the table below. When flashing the “VENTILATOR
FAILURE” message on the display, the associated audible tones may be used to identify which solenoid has
failed:
MESSAGE FAILED COMPONENT AUDIBLE SEQUENCE
LOW BATTERY, CONNECT
EXTERNAL POWER
N/A 1 LONG
LOW SUPPLY PRESSURE N/A 1 LONG
VENTILATOR FAILURE SOLENOID A 1 LONG, 1 SHORT
VENTILATOR FAILURE SOLENOID B 1 LONG, 2 SHORT
VENTILATOR FAILURE SOLENOID D1 2 LONG, 1 SHORT
VENTILATOR FAILURE SOLENOID D2 2 LONG, 2 SHORT
VENTILATOR FAILURE SOLENOID D3 2 LONG, 3 SHORT
VENTILATOR FAILURE PNEUMOTACH
TRANSDUCER
1 LONG
NOTE: For a full list of beeper codes, see Appendix E.
