3) Press TEST twice more to return the system to normal
operating mode.
DISPLAY UNIT FUSE INSPECTION AND REPLACEMENT
The following section provides the procedure to remove the
Fuse Holder. Refer to Figure 2-3, which shows the rear
panel of the Atomlab Display Unit, and Figure A-1, which
illustrates the actual Fuse Holder replacement procedure.
Due to the possibility of electrical shock, danger
of injury to yourself, and damage to the equipment, does
exist. Be sure to switch the power OFF, and unplug the unit,
before proceeding.
Due à la possibilité de choc électrique, il
existe un danger de vous blesser ou de causer des dom-
mages à l’équipement. Assurez-vous de bien fermer l’ap-
pareil et de le débrancher avant de procéder.
1) Rotate the Display Unit so that you are looking at the
rear panel. Directly to the right of the connector labeled
CHAMBER (between the power plug and ON/OFF
switch), locate the Fuse Holder. This is labeled in the
center with USE ONLY WITH 250V FUSES, on the
bottom with100V-120V read upright and on the top with
200V-240V read upside down.
2) The orientation of the Fuse Holder determines the
Orientation power the Atomlab unit requires. If the label
100V-120V can be read upright (the label 200V-240V is
upside down), and the corresponding arrow directly
below the label points to the arrow on the rear panel
directly below the Fuse Holder, then you must plug your
dose calibrator into an 100 VAC power source.
If, conversely, the label 200-240 can be read upright (the
label 100V-120V is upside down), and the corresponding
arrow directly below the label points to the arrow on the
rear panel directly below the Fuse Holder, then you must
plug your dose calibrator into a 200 VAC power source.
ATOMLAB Dose Calibrator Operation Manual Appendix A
Biodex Medical Systems A-4 Release 2.0
Procedure
