The following fuses must be used:
100-120 VAC Two SLO-BLO 5x20 mm 1/2 Amp
200-240 VAC Two SLO-BLO 5x20 mm 1/4 Amp
The danger of damage to the equipment exists. Be
sure you properly orient the Fuse Holder prior to replacing it.
Danger de dommage à l’ équipement.
Assurez-vous de bien orienter le support de fusibles acant
de le remplacer.
To replace the Fuse Holder, position it into the indentation
from which it was removed and gently push it back into
place. It is critical to first determine the particular power
requirement (100 VAC or 240 VAC) and ensure the Fuse
Holder is properly oriented before turning the system back
ON. See step 2), above.
SETTING UP FOR 100 VAC OR 240 VAC
Figure 2-3 shows the proper orientation of the Fuse Holder
to set up your Dose Calibrator for 100 VAC operation. The
Fuse Holder contains two 1/2 Amp, 250 VAC fuses.
If you should wish to set up your system to accept 240
VAC, remove the Fuse Holder, as described above, replace
the existing fuses with 1/4 Amp, 250 VAC fuses, and then
replace the Fuse Holder with the proper orientation.
IMPORTANT NOTES ABOUT SYSTEM ERRORS
Following the Self-Test, if a fault has been detected the
TEST LED will remain on and the Electronic Thumbwheel
Display (#1) will show the first error message in the Form
"Er.1, Er.2", etc. Each time you press the TEST key the next
Error Message, if further faults have been detected, will be
displayed. The TEST LED will flash continuously to inform
you that more errors have been detected.
ATOMLAB Dose Calibrator Operation Manual Appendix A
Biodex Medical Systems A-6 Release 2.0
Fuse
Replacement
Fuse Holder
Replacement
