3) There is a small indentation to the left of the Fuse
Holder. Insert the end of a flat-edged screwdriver into
the indentation and gently pry the Fuse Holder out
slightly. Now, use your fingers to pull the Fuse Holder
out of the panel.
Once the Fuse Holder is removed, inspect the filament at the
center of the two fuses. If it is burned or broken in any way the
fuse must be replaced. If the filament does not appear to be
broken or burned, test the fuse for continuity with an ohm
meter.
Figure A-1: Removing the Fuse Holder
ATOMLAB Dose Calibrator Operation Manual Appendix A
Biodex Medical Systems A-5 Release 2.0
Fuse Inspection
