Standard Test Method Range Limits Result
IEC 61000-3-2 Harmonics 100 Hz to 2KHz Class A THD = 39.77%
IEC 61000-3-3 Flicker observation time (TP) 10 min - -
max voltage change (dmax) 4% .24%
max Rel steady state voltage change (dc) 3% .03%
duration of d(t)>3%(t)
.2 sec 0.00 sec
short term flicker Sev (PST) 1.00 .04
long term flicker Sev (PLT) .65 .04
IEC 61000-4-2 Electrostatic Discharge 4 Kv + 6Kv pos/neg 1pps for 10 sec no degradation of performance complied
IEC 61000-4-3 Radiated Immunity 1 KHz to 2500 MHz/3v/m/Horiz &
Vertical
no degradation of performance complied
IEC 61000-4-4 Electrical Fast Transient/Burst,
Power Leads
PWR Input leads 2 Kv/pos+neg/5KHz
REP Rate
no degradation of performance complied
IEC 61000-4-6 Conducted Immunity,
Power Leads
150 KHz to 80 MHz /3Vrms no degradation of performance complied
IEC 61000-4-8 Magnetic Immunity 3A/M RMS @ 50/60 Hz no degradation of performance complied
IEC 61000-4-11 Voltage Dips and Interrupts Int
Duration
Pause
between
%
reduction
no degradation of performance complied
Int 20msec pause 10 sec >95% no degradation of performance complied
Int 100msec pause 10 sec 60% no degradation of performance complied
Int 500msec pause 10 sec 30% no degradation of performance complied
Int 5000msec pause 10 sec >95% no degradation of performance complied
CISPR 11 Conducted Emissions 150 KHZ-30 MHz, Class A, Group 1 79/73 dbuV QP
66/60 dbuV AV
complied
CISPR 11 Radiated Emissions 30 MHz – 1GHz, Class A, Group 1 40/47 dbuVm @ 10 m complied
IEC 61000-4-5 Surge Immunity,
Power Leads
1 Kv, differential, 2 Kv Commons
Pos, Neg
no degradation of performance complied
Date: 3/8/05
Atomlab\Rick Prince - dc methods test.doc :cs:dv
