BIXOLON XD5-40DK - Button & LCD (LCD Model); Button Operation

Ver. 1.02
- 23 -
XD5-40d Series
3-6 Button & LCD (LCD Model)
3-6-1 Button Operation
Printer state
before
operation
Button
Explanation
Print Ready
Menu Move
Move to the next menu
(The menu moves from the top left to the bottom
right)
Print Ready
Menu Select
Select menu or change value
In Menu or
Print Ready
Function
Button 1
Pause , Print, Save, Main screen display
In Menu or
Print Ready
Function
Button 2
Feed, Cancel, Previous screen display
Menu
Move
Function
Button 1
Menu
Select
Function
Button 2
