XD5-40d Series
3-6-2 Interface Status Icon
User can check the status and setting information through the LCD.
Icon
Explanation
Bluetooth is not connected to the host
Bluetooth is connected to the host
Authentication is failed
Not connected to AP
Connected to AP, Strength: 4
Connected to AP, Strength: 3
Connected to AP, Strength: 2
Connected to AP, Strength: 1
Ethernet is connected
USB storage is connected
