XD5-40d Series
5-11 Media Installation Method of Peeler (Option) Model
• Use a peeler to separate the printed media from the liner automatically.
To use peeler, install media in the following ways:
1) Open the media cover.
2) Open the peeler cover.
3) Set the peeler switch ‘ON’ position and check to LED has turned on.
LED
Peeler Switch
ON
