BIXOLON XD5-40DK - Setting Menu Explanation

Ver. 1.02
- 28 -
XD5-40d Series
3-6-4 Setting Menu Explanation
Menu
Explanation
Width
(Print Width)
Explanation
Setting media width[dots]
Function to adjust image buffer size according to print width
Default Value
- 203dpi : 864 dots (108mm)
- 300dpi : 1,248 dots (105.7mm)
Maximum Value
- 203dpi : 864 dots (108mm)
- 300dpi : 1,248 dots (105.7mm)
Length
(Print Length)
Explanation
Setting media length[dots]
Function to adjust image buffer size according to print length
Default Value
203dpi : 1,225 dots (153mm)
300dpi : 1,811 dots (153mm)
Maximum Value
- 203dpi : 8,000 dots (1,000mm)
- 300dpi : 11,820 dots (1,000mm)
