BIXOLON XD5-40DK - When Using Fan-Fold Media

Ver. 1.02
- 58 -
XD5-40d Series
5-12-1 When using Fan-Fold media
Supplying fan-fold media to the printer externally is done as follows.
1) Insert the media to at the rear of the printer as shown below.
2) Adjust media holders to the media width by using the fix tool.
Fix Tool
Media Holder
