5-5 B/M Sensor Auto Calibration Mode
• Black mark sensor auto calibration mode is used when the printer does not detect
a black mark on the media correctly.
Generally a printer is set to detect most types of black mark but sometimes it fails to
detect and keep feeding the media without a stop when special media used. In such case,
use black mark sensor auto calibration mode function for a proper detection.
1) Make sure that media roll has been installed properly.
(1) Standard Model
Using stand-alone configuration mode, press the Feed/Cancel button( )
at sequence number 5 black mark sensor auto calibration (refer to 5-1).
(2) LCD Model
In print ready mode the setting menu and move to Sensor Black Mark Cal(Black
Mark Calibration) and press Function button 1( ) to process black mark sensor
auto calibration
* Please refer Tools Menu Explanation (3-6) for more information.
Contact the customer center if the printer does not execute
black mark sensor auto calibration mode function.
