Bizerba FK 23 User Manual

Operating instructions FK 23 About this machine
6.066.98.5.10.05 en 2 - 3
2
2.2.1 Naming of FK 23 components
Fig. 1: Naming of FK 23 components
The machine is available in different versions. The figure shows an example:
1
Deflection roller
2
ON/OFF switch
3
Product pusher
4
Star knob, material pusher
5
Spherical button, material pusher
6
Work table
7
Disk deflector
8
Lever, saw blade clamping unit
9
Saw blade
10
Drive disk
11
Adjustment device, upper wheel
12
Handle
13
Star knob
14
Star knob, protective rail
15
Protective rail with saw-blade feed
16
Gauge plate
17
Star handle, stop plate

Bizerba FK 23 Specifications

General

Brand	Bizerba
Model	FK 23
Category	Saw
Language	English
