About this machine Operating instructions VS12D /C /-R /-V /-
V/R
2 - 2 6.083.98.5.10.10 en
2
Applications
The slicers in the VS12D series are intended for installation in the sales area. Installation
in preparation areas is permissible, making allowances for a cleaning plan and protection
type IP 33.
Permissible ambient temperatures from -10°C up to 40°C.
Operating time
The slicers are designed for permanent operation.
2.2 Machine description
Drive
The drive systems for blade, carriage, depositing table, depositing arm and chains are
separated. The blade motor is operated with supply voltage; the other drives are operated
with mains voltage.
The contactor control having a self-locking circuit prevents automatic restarting after a
power cut.
The membrane keyboard On/Off with signal lamp is located on the motor tower.
The functional keys are integrated in the membrane keyboard.
Depositing system
The slicer is equipped with an automatic slice depositing system. The depositing system
deposits slices with a max. slice thickness of 8 mm. A max. slice thickness of 24 mm can
be reached without depositing system and with unlocked slice thickness limit.
The depositing system consists of a chain frame with transport chain, feed roller with guide
cam as well as depositing arm and depositing table incl. paper holder.
The depositing system is controlled by means of an encoder depending on carriage speed
and carriage stroke.
Product holder
The product holder can be lifted up into an unstable equilibrium in order to insert the prod-
uct for slicing (VS12D).
The product holder can be locked or unlocked in order to insert the product. Can be re-
moved for cleaning (VS12D-V).
Carriage
The carriage with the additional product fixation holds the sliced product (VS12D) in place
and prevents it from slipping or tilting.
The carriage with the product fixation holds the sliced product in place and prevents it from
slipping or tilting (VS 12D-V).
At a slice thickness set below "0" the tilting device of the carriage is unlocked. This allows
the carriage to be tilted to the outside in any position.
