Technical data
6.083.98.5.10.10 en 9 - 1
9
9
Technical data
9.1 Dimensions VS12D
Fig. 69: VS12D, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 620 mm = 24.4"
2
Width
= 795 mm = 31.3"
3
Height
= 551 mm = 21.7"
Installation surface:
4
Length
= 515 mm = 20.3"
5
Width
= 430 mm = 16.9"
Work area:
6
Length
= 800 mm = 31.5"
7
Width
= 980 mm = 38.6"
Weight = approx. 71 kg = 70.76 kg
Blade diameter = 330 mm = 13"
Blade speed = 266 rpm
Number of carriage
strokes
= approx. 30 - 70 strokes/min
