Bizerba VS12D - Page 14

About this machine Operating instructions VS12D /C /-R /-V /-
V/R
2 - 4 6.083.98.5.10.10 en
2
The machine is available in different versions. The figure shows an example:
1
Blade guard ring
2
Blade
3
Blade cover
4
Pusher protection
5
Locking lever
6
Remnant holder plate
7
Remnant holder
8
Product fixation device
9
Carriage
10
Handle for product holder
11
Star knob for carriage
12
Rating plate
13
Unlocking of slice thickness control
14
Slice thickness setting
15
Push button operating mode
16
Table guide
17
Depositing table with paper holder
18
Deflector
19
Gauge plate
20
Depositing arm
21
Back panel
22
Feed roller with cam
23
Three-square knob for blade cover
24
Chain frame
25
Membrane keyboard
