Operation Operating instructions VS12D /C /-R /-V /-
V/R
6 - 6 6.083.98.5.10.10 en
6
Setting possibilities
Fig. 25: Deposit on round platter
In order to obtain a depositing pattern
(see picture) the number of slices has to
be increased accordingly.
Circular pattern depositing of rectangular
products is only possible by using the
round platter.
Standard pre-setting: Depositing program <Circular pattern> with 5 slices per circular
pattern.
The number of slices can be changed to up to 99 slices per circular pattern and circle di-
ameter.
Depositing programs <Stacking 2 times> and <Shingling transversal>
cannot be selected with the round platter placed on the machine.
