Operating instructions VS12D /C /-R /-V /-
V/R
Maintenance
6.083.98.5.10.10 en 8 - 13
8
Carriage
Fig. 50: Tilting carriage, VS12D
Fig. 51: Tilting carriage, VS12D-V
Tilt carriage.
Using the handle screw into place on
the carriage foot.
Support plate VS12D
Fig. 52: Support plate VS12D
Insert support plate from top, screw it to
guide piece with star knob screw.
