1.6 Display Overview
Display Description
Setting/Measured Voltage
Measured Power Output
Settings Display
Displays parameter settings such as OVP, P-max, Rise/Fall
Setting/Measured Current
OFF Indicates output is disabled
CC Indicates constant current (CC) operation
CV Indicates constant voltage (CV) operation
Rmt Indicates remote mode
Addr Indicates remote communication activity
Error Indicates an error has occurred
Trig Indicates waiting for trigger (for list operation)
Prot Indicates protection trip for over voltage or over temperature
* Indicates key lock is enabled
Shift Indicates shift mode (for access to secondary button functions)
OFF CC CV Rmt Addr Error Trig Prot * Shift
Figure 1.5 – Display Overview
