42
2. No
w, press twice to exit the menu. The following will display:
3. If t
he display is showing the measured voltage and current value, the backlight
should be lit and display should show 0.000V and 0.000A.
4. Now, press the key to enable (ON) the output.
5. If the Trigger Source configured in section 3.3 is set to Manual (Def), then the front
panel trigger key can be used to initiate the program. Press and then .
6. The program will immediately start running and the backlight of the button will
be blinking. The Trig indicator will also disappear.
7. When the program ends, the will stop blinking and the Trig indicator will
reappear again.
Note: If the Trigger Source is configured to BUS, use the remote command for sending
triggers over any of the remote interface available. Refer to the programming
3.6 9115-AT Automotive Test Functions
The 9115-AT power supply has a unique automotive testing feature built-in that allows the user
to run stress tests based on the DIN 40839 and ISO 16750-2 standards. The functions have the
ability to test 12 volt and 24 volt systems. For details on the DIN 40839 and ISO 16750-2
standards, please see www.din.de (DIN standards) and www.iso.org (ISO standards).
DIN 40839 Parameters
The DIN40839 function simulates a test pulse based on the DIN 40839 standard. The standard
pulse shape and parameters are shown below:
Note: This functionality is only available on model 9115-AT.
