26
1. From the CONFIG menu, browse and select Ext-Ctrl and press . The following
screen will display:
2. Select 10v-M or 5v-M so that it is blinking. Use the keys to change between 10v-
M and 5v-M. – 0 – 5 V scale is used for monitoring 0 – 100% of output.
10v-M – 0 – 10 V scale is used for monitoring 0 – 100% of output.
3. Press when finished making the selection.
4. Press several times to exit the menu.
Configure Control Source
Follow the steps below to configure the source to use for programming the voltage and current
output.
Note: Voltage programming is on Pin 20 and current programming is on Pin 22 of the
DB25 Analog interface.
1. From the CONFIG menu, browse and select Ext-Ctrl and press . The following
screen will display:
2. Select the second item 10v/10k-P or 5v/5k-P so that it is blinking. Use the keys
to change between 10v/10k-P and 5v/5k-P.
5v/5k-P – 0 – 5 V (for voltage) or 0 – 5 kΩ (for resistance) is used for programming the
voltage and current output.
10v/10k-P – 0 – 10 V (for voltage) or 0 – 10 kΩ (for resistance) is used for programming
the voltage and current output.
