37
Pressing the same number will change the “Y” back to the corresponding number. For
example, if you want to configure and store a sequence with steps 1, 4, 6, and 8, press 1,
4, 6, and 8 on the numeric keypad so that the following will display:
7. For this example, steps 1, 2, 3, 4, and 5 will be used, so use the numeric keypad and
press 1, 2, 3, 4, and 5 until it displays:
8. Once set, press . The display will change to the following:
9. This is prompting the user to enter the voltage setting for step 1. Use the voltage and
current adjust knob or the numeric keypad and enter 1.000. Then press .
10. The display will change to the following, prompting the user to enter the current setting
for step 1.
11. Similar to entering the voltage setting in the previous step, do the same to enter 1.000
as the current setting. Then press . Now, the following will display:
Seq Step 1 Current = 1.000A
Seq Step 1 Voltage = 1.000V
