Remove screw 1 on the in-
board side of the right side
panel.
Remove screws 2.
Remove screws 3 with the
washers.
Pull the fairing side panel at
position 4 to disengage it from
the rubber buffer and remove.
Work the cable through the
fairing side panel.
Hold the flashing turn indicator
in position and install screw 2.
Clip in the turn-signal cable at
position 1.
Installing side panel ( 138).
6
112
z
