Install screw hole covers 1.
Cover for rear footrests
on the rear frame
without Passenger
Bundle
OE
3 Nm
Installing rear footrests
with Passenger Bundle
OE
Remove screw 2 with nut and
washers.
Stretch out retaining strap 1
and pull backwards from the
silencer.
Remove screws 1 and remove
the silencer strap.
Hold the footrest and install
screw 1 (M8x25), tightening to
the specified torque.
8
126
z
Accessories
