9) Manual testing of circuits
While the status of a relay is displayed, it is possible to test it.
Select the circuit you wish to test with the
key.
The system recognises its mode of
assignment (relay or melody).
If the circuit is a relay circuit, start the test
with the key.
If you press it briey (for less than 3 seconds), the relay is activated (ON
position) for as long as the key is pressed.
If you press it for a longer period (more than 3 seconds), the relay is activated
(ON position), and if you press it again the relay is deactivated (OFF position).
If the circuit is a melody circuit,
You can select the melody to be tested with
and keys.
Start the test with the key.
If you press it briey (for less than 3 seconds) = the melody is played once.
If you press it for a longer period (more than
3 seconds) = the melody is played loop until
you press it again.
Circuit 12: START ú
Access control ok
Cir.12: START TEST
Access control ok
Cir.ô12: START MEL01
Access time ok
Cir.61ô: FORCED TEST01
STOP TEST : ok
