3) Description
Wall box
A) LCD screen
B) Keypad (see page 16)
C) Alarm indicator light (red
LED)
D) Mains indicator light (green
LED)
E) USB connector
F) Relay output terminal strips
19” Rack
E
A
C
D
B
D
C
A
E
B
