Bodet Sigma Mod - Page 37

37
Buzzer mode allows you to activate a buzzer on the secondary transmitters in
order to identify them.
For an “impulse” or “D1D2” output, the
key can be used to go to the conguration
menu.
Remark: the “D1D2” menu appears only if the relays have been assigned to
the D1D2 distribution (see “Relay setting menu”, page 39).
Use the key to move on to the next parameter:
Choice of impulse length.
Minute 24V standard impulse length (factory conguration) of 1.2
seconds variable from 0.5 to 5 seconds,
Second 24V standard impulse length (factory conguration) of 0.3
seconds variable from 0.1 to 0.9 seconds,
D1D2 standard impulse length (factory conguration) of 6 seconds,
variable from 1 to 10 seconds.
Use the key to move on to the next
parameter:
Choice of status (“Start”/“Stop”).
Circuit stopping must be conrmed.
Use the key to return to the previous screen.
D1D2 minute:06s ú
START 00:00 ok
Caution STOP mode ok
on D1D2 output exit C
