Reference frequency source 475
1 - Abs. value analog value MFI1A
Reference value source is the multifunctional input 1 in
analog Operation mode 452.
2 - Abs. Analog Value EM-S1INA
Reference value source is the analog input of the ex-
pansion module.
Abs. Value MFI1A + EM-S1INA
Combination of the operation modes 2 and 1.
10 - Abs. value fixed frequency (FF)
The fixed frequency according to the Fixed frequency
change-over 1 66 and Fixed frequency change-over 2
67 as well as the current data set.
11 - Abs. value MFI1A + FF Combination of the operation modes 10 and 1.
Combination of the operation modes 10 and 2.
Abs. Value MFI1A + EM-S1INA + FF
Combination of the operation modes 10, 1 and 2.
20 - Abs. value Motorpoti (MP)
Reference value source is the function Frequency Mo-
torpoti Up 62 and Frequency Motorpoti Down 63.
Combination of the operation modes 20 and 1.
Combination of the operation modes 20 and 2.
Abs. Value MFI1A + EM-S1INA + MP
Combination of the operation modes 20, 1 and 2.
30 - Abs.Val. Speed Sensor 1 (F1)
The frequency signals in Operation mode 490 are eval-
uated as a reference value.
31 - Abs. value MFI1A + F1 Combination of the operation modes 30 and 1.
32 -
Abs. value repetition freq.-/PWM
input (F3)
The frequency signal on the digital input according to
Operation mode 496 for the PWM-/ repetition frequen-
33 - Abs. value MFI1A + F3 Combination of operation modes 1 and 32.
34 - Abs.Val. Speed Sensor 2 (F2)
The frequency signals in Operation mode 490 are eval-
uated as a reference value.
35 - Abs. Value MFI1A + F2 Combination of operation modes 1 and 34.
40 - Abs. value Motorpoti (KP)
KP 500 is the reference value source, with keys â–˛ for
increasing the frequency and â–Ľ for reducing the fre-
41 - Abs. value MFI1A + KP Combination of operation modes 40 and 1.
42 - Abs. Value EM-S1INA + KP Combination of operation modes 40 and 2.
44 - Abs. Value MFI1A + EM-S1INA + KP Combination of operation modes 40, 1 and 2.
80 -
Abs. value MFI1A + FF + KP + F3
+ (EM-S1INA)1)
Combination of the operation modes 1, 10, 40, 32
and 2.
1)
81 -
Abs. value MFI1A + FF + KP + F1 +
F3 + (EM-S1INA)
1)
Combination of the operation modes 1, 10, 40, 30, 32
and 2.
1)
82 -
Abs. value MFI1A + FF + KP + F3
+ (F2)
2)
1)
Combination of the operation modes 1, 10, 40, 32, 34
2)
and 2.
1)
89 -
Abs. value MFI1A + FF + KP + F1 +
F3 + (F2)
2)
1)
Combination of the operation modes 1, 10, 40, 30, 32 ,
34
2)
1)
90 -
Abs. value MFI1A + FF + MP + F3
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 32 and
2.
1)
91 -
Abs. value MFI1A + FF + MP + F1
+ F3 + (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 30, 32
and 2.
1)
92 -
Abs. value MFI1A + FF + MP + F3
+ (F2)2) + (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 32, 34
2)
and 2.
1)
99 -
Abs. value MFI1A + FF + MP + F1 +
F3 + (F2)2) + (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 30, 32,
34
2)
1)
101 to 199 Operation modes with signs (+/-)
1)
The reference value source is only available if an expansion module with analog input is connected. For infor-
mation, refer to the expansion module operating instructions.
2)
The reference value source is only available if an expansion module with speed sensor input is connected. For
information, refer to the expansion module operating instructions.
06/13 Operating Instructions ACU 155
