BONFIGLIOLI ACTIVE Cube ACU 201-11 User Manual

Digital Outputs
No.
Description
Unit
Setting range
Chapter
542 Comparator Off below % -300.00 ... 300.00
15.5.2
543
Operation mode comparator 2
-
Selection
15.5.2
544
Comparator On above
%
-300.00 ... 300.00
15.5.2
545
Comparator Off below
%
-300.00 ... 300.00
15.5.2
549
Max. Control Deviation
%
0.01 ... 20.00
15.3.3
Multifunctional output 1
550
Operation mode
-
Selection
15.2
551
Voltage 100%
V
0.0 ... 22.0
15.2.1.1
552
Voltage 0%
V
0.0 ... 24.0
15.2.1.1
553
Analog operation
-
Selection
15.2.1
554 Digital operation - Selection
15.3
Multifunctional output 1
555
Repetition frequency operation
-
Selection
15.2.2
556
Division Marks
-
30 ... 8192
15.2.2.1
Error/warning behavior
570
Motor Temp. Operation Mode
-
Selection
13.6
Motor protection switch
571 Operation mode - Selection
18.5
572
Frequency Limit
%
0 ... 300
18.5
Intelligent current limits
573
Operation mode
-
Selection
17.1
574 Power Limit % 40.00 ... 95.00
17.1
575 Limitation time min 5 ... 300
17.1
Error/warning behavior
576
Phase supervision
-
Selection
13.7
578 Allowed no. of auto-acknowl. - 0 ... 20
13.8
579 Restart delay ms 0 ... 1000
13.8
Pulse Width Modulation
580
Reduction Limit Ti/Tc
deg.C
-25 ... 0
18.1
V-belt Monitoring
581
Operation mode
-
Selection
18.5.2
582
Trigger limit Iactive
%
0.1 ... 100.0
18.5.2
583
Delay time
s
0.1 ... 600.0
18.5.2
V/f characteristic
600
Starting voltage
V
0.0 ... 100.0
16
601
Voltage rise
%
-100 ... 200
16
602
Rise frequency
%
0 ... 100
16
603
Cut-off voltage
V
60.0 ... 560.0
16
604 Cut-off frequency Hz 0.00 ... 999.99
16
605 Dyn. voltage pre-control % 0 ... 200
16.1
Current limit value controller
610
Operation mode
-
Selection
17.4.2
611
Amplification
-
0.01 ... 30.00
17.4.2
612 Integral time ms 1 10000
17.4.2
613 Current Limit A
0.0 ... o
⋅
I
FIN
17.4.2
614
Frequency Limit
Hz
0.00 ... 999.99
17.4.2
Error/Warning Behaviour
617 Max Temp. Windings °C 0 … 200
13.6
Technology Controller
618
Derivative Time
ms
0 … 1000
17.3
282 Operating Instructions ACU 06/13
