15.3.1 Digital Signal
The signals selected for parameters Op. Mode Digital Output 1 530, Digital Opera-
tion 554 and Op. Mode Digital Output 3 532 can be linked with inverter functions.
Signal at digital output 1
175 - Digital Signal 1
The Signal which is selected via Op. Mode Digital Out-
put 1
530.
Signal at multifunction output MFO1
176 - Digital Signal 2
The Signal which is selected via Digital Operation 554.
Set Operation Mode 550 = 1 - Digital.
Signal at digital output 3 (relay output)
177 - Digital Signal 3
The Signal which is selected via Op. Mode Digital Out-
put 3 532.
With expansion module:
Signal at digital output 1 of an expansion module
181 -
Digital Signal 4,
EM-Module
The signal, which is selected via Op. Mode EM-
S1OUTD 533.
Signal at digital output 2 of an expansion module
182 -
Digital Signal 5,
EM-Module
The signal, which is selected via Op. Mode EM-
S2OUTD 534.
06/13 Operating Instructions ACU 183
