Via parameter Operation mode 435, the drive is configured as a master drive or
slave drive.
The traverse function is deactivated.
Operation as master drive.
Operation as slave drive.
For traverse mode, the reference value source is selected via parameter Reference
frequency 48.
Traverse mode becomes active as soon as the Reference frequency 48
the first time. This frequency is reached via the values for Acceleration (clockwise)
420 and Acceleration Anticlockwise 422 and Deceleration (clockwise) 421
Deceleration anticlockwise 423. In shot-effect mode, the values for Acceleration
Time
436 and Deceleration Time 437 are active.
The frequency range for shot-effect mode is limited by the Minimum frequency 418
and the Maximum frequency 419.
During traverse operation, the configured traverse parameter values cannot be
changed.
The source of the handshake signal is selected via Handshake Traverse Function 49.
06/13 Operating Instructions ACU 255
