BONFIGLIOLI ACTIVE Cube ACU 401-15

Modulation Controller
No.
Description
Unit
Setting range
Chapter
753
Operation mode
-
Selection
17.5.7
Modulation Controller
754
Filter time constant
ms
0…128
17.5.4
Modulation Controller
755
Reference Imr lower limit
A
0.01⋅I
FIN
... o⋅I
FIN
17.5.7.1
756
Control deviation limitation
%
0.00 ... 100.00
17.5.7.1
Current Controller
757
Current below P. 700 is in effect
A
0.00⋅ ... o⋅I
FIN
17.5.2
758
Current above P. 759 is in effect
A
0.00⋅ ... o⋅I
FIN
17.5.2
759
Amplification high Current
-
0.00 ... 8.00
17.5.2
Speed Sensor Monitoring
760
Operation mode
-
Selection
18.7.3
761
Timeout: Signal fault
ms
0 ... 65000
18.7.3
762
Timeout: Track fault
ms
0 ... 65000
18.7.3
763
Timeout: Direction of rotation fault
ms
0 ... 65000
18.7.3
Speed controller
766
Source of actual speed value
-
Selection
17.5.4
Torque Controller
767 Frequency upper limit Hz -999.99 ... 999.99
17.5.2
768 Frequency lower limit Hz -999.99 ... 999.99
17.5.2
769
Frequency upper limit source
-
Selection
17.5.2
770
Frequency lower limit source
-
Selection
17.5.2
Current Controller
775 Current above P. 700 is in effect A 0.00⋅ ... o⋅I
FIN
17.5.2
776
Current below P. 777 is in effect
A
0.00⋅ ... o⋅I
FIN
17.5.2
777
Amplification low Current
-
0.00 ... 8.00
17.5.2
Field Controller
778 Reduction Factor Flux % 20.00 … 100.00
17.5.6
Starting Behavior
779
Min. Flux-Formation Time
ms
1 … 10000
12.1.2
780
Max. flux formation time
ms
1 ... 10000
12.1.2
781 Current during flux formation A
0.1⋅I
FIN
... o⋅I
FIN
12.1.2
Timer
790
Operation mode Timer 1
-
Selection
15.5.1
791
Time 1 Timer 1
s/m/h
0 ... 650.00
15.5.1.1
792 Time 2 Timer 1 s/m/h 0 ... 650.00
15.5.1.1
793 Operation mode Timer 2 - Selection
15.5.1
794
Time 1 Timer 2
s/m/h
0 ... 650.00
15.5.1
795
Time 2 Timer 2
s/m/h
0 ... 650.00
15.5.1
Self-configuration
796 SET-UP Select - Selection
8.5
Further motor parameters
1190
Stator Resistance
Ohm
0.001 … 100.000
10.2.1
1192
Peak current A
0.01% I
FIN
…
100 000% o I
FIN
10.2.7
Filter encoder 1
1193
EC1: Filter time constant
us
0…32000
10.4.4
Further motor parameters
1199
Change Sense of Rotation
-
Selection
10.2.8
06/13 Operating Instructions ACU 285
