8.3.2 0x603F/0 error code (integer 16)
In the object error code, the last error which has occurred is stored.
Accordin
g
to DS402, a lar
g
e number of possible error reports have been specified. The
following list shows the interconnection between the error code displayed internally by
the frequency inverter and displayed on control unit KP500 and the error secured in
the object error code.
Error reports
Error Error code Meaning
F00 xx 00 00 No error has occurred
Overload
F01 xx 23 10 Frequency inverter has been overloaded
Case
F02 xx 42 10 Case temperature outside the temperature limits
Inside
F03 xx 41 10 Inside temperature outside the temperature limits
Motor connection
F04 xx 43 10 Motor temperature too high or sensor defective
Output current
F05 xx 23 40 Motor phase current above the current limit
DC link voltage
F07 xx 32 10 DC link voltage outside the voltage range
Electronic voltage
F08 xx 51 11 Electronic voltage outside the voltage range
Motor connection
F13 xx 23 30 Earth fault on frequency inverter output
Generic error
Fyy xx 10 00 Other error reports
If 1000 = generic error appears as the error code, the error code can be read off via
parameter
Current error 260. The parameter Current error 260 contains the error
code in the product-internal format.
The assignment table of the error code to the reports in question can be seen from
the operating instructions.
In the emer
g
ency messa
g
e, the error code of the frequency inverter is transmitted on
bytes 4 ... 7.
