10 Parameter list
The parameter list is structured according to the menu branches of the operating unit.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SET-UP routine.
This parameter cannot be written in the operation of the frequency inverter.
10.1 Actual value
Actual values of the frequency inverter
No. Description Unit Display range Chapter
228 Internal reference frequency Hz -1000.00 ... 1000.00 9.4
249 Active data set - 1 ... 4 9
250 Digital inputs - 0 ... 255 9.3
260 Current error - 0 ... 0xFFFF 8.3.2
270 Warnings - 0 ... 0xFFFF 9.1
282 Reference bus frequency Hz -1000.00 ... 1000.00 9.4
283 Reference ramp frequency Hz -1000.00 ... 1000.00 9.4
Note:
The parameters
Current error 260
and Warnings 270
are only accessible
via the manufacturer ob
jects 0x2nnn. It cannot be addressed via the
VPlus program or the KP500 control unit.
10.2 Parameter
Rated motor parameters
No. Description Unit Display range Chapter
373 No. of pole pairs - 1 ... 24 8.5.1
Bus control
392 State-transition 5 - 0 ... 2 9.2
412 Local/Remote - 0 ... 44 9
Data set change-over
414 Data set selection - 0 ... 4 9
Frequency ramps
420 Acceleration (Clockwise) Hz/s 0,01 ... 999,99 8.5.6
421 Deceleration (Clockwise) Hz/s 0,01 ... 999,99 8.5.7
422 Acceleration (Anticlockwise) Hz/s -0,01 ... 999,99 8.5.6
423 Deceleration (Anticlockwise) Hz/s -0,01 ... 999,99 8.5.7
424 Emergency stop (Clockwise) Hz/s 0,01 ... 9999,99 9.2.1
425 Emergency stop (Anticlockwise) Hz/s 0,01 ... 9999,99 9.2.1
Frequency ramps
434 Ramp set point - 1 ... 3 9.4
Digital outputs
549 max. Control deviation % 0,01 ... 20,00 9.1
Stopping behavior
637 Switch-off threshold % 0,0 ... 100,0 9.2.1
638 Holding time" s 0,0 ... 200,0 9.2.1
Note:
The parameter
Data set selection 414
is only accessible via the
manufacturer ob
ects 0x2nnn. It cannot be addressed via the VPlus
program or the KP500 control unit.
