BONFIGLIOLI AS Series User Manual

55
AS 20
100 Nm
AS 20_ 5.49 510 50 2.8 600 730 255 60 1.7 600 950
73
AS 20_ 6.46 433 50 2.4 600 800 217 60 1.4 600 1040
AS 20_ 7.75 361 50 2.0 600 890 181 60 1.2 600 1150
AS 20_ 8.57 327 50 1.8 600 940 163 60 1.1 600 1210
AS 20_ 9.92 282 55 1.7 600 940 141 65 1.0 600 1220
AS 20_ 11.67 240 55 1.5 600 1030 120 65 0.86 600 1340
AS 20_ 14 200 55 1.2 600 1140 100 65 0.72 600 1470
AS 20_ 15.48 181 55 1.1 600 1200 90 65 0.65 600 1540
AS 20_ 18.01 155 80 1.4 600 1040 78 80 0.68 600 1490
AS 20_ 21.19 132 80 1.2 600 1150 66 80 0.58 600 1620
AS 20_ 25.43 110 80 0.97 600 1280 55 80 0.48 600 1780
AS 20_ 28.13 100 80 0.88 600 1350 50 80 0.44 600 1880
AS 20_ 31.71 88 80 0.78 600 1390 44 80 0.39 600 1940
AS 20_ 37.31 75 80 0.66 600 1530 38 80 0.33 600 2100
AS 20_ 44.77 63 80 0.55 600 1680 31 80 0.28 600 2290
AS 20_ 49.52 57 80 0.50 600 1770 28.3 80 0.25 600 2400
AS 20 D_ 58.1 48 90 0.49 330 1810 24.1 90 0.24 330 2476
AS 20 D_ 64.3 44 90 0.44 330 1910 21.8 90 0.22 330 2595
AS 20 D_ 69.2 40 90 0.41 330 1930 20.2 90 0.21 330 2632
AS 20 D_ 81.4 34 90 0.35 330 2100 17.2 90 0.17 330 2800
AS 20 D_ 97.7 28.7 90 0.29 330 2300 14.3 90 0.15 330 2800
AS 20 D_ 108.1 25.9 90 0.26 330 2410 13.0 90 0.13 330 2800
AS 20 D_ 120.1 23.3 90 0.24 330 2470 11.7 90 0.12 330 2800
AS 20 D_ 141.3 19.8 90 0.20 330 2680 9.9 90 0.10 330 2800
AS 20 D_ 169.5 16.5 90 0.17 330 2800 8.3 90 0.08 330 2800
AS 20 D_ 187.5 14.9 90 0.15 330 2800 7.5 90 0.08 330 2800
i
n
1
= 2800 min
-1
n
1
= 1400 min
-1
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
1
= 900 min
-1
n
1
= 500 min
-1
AS 20_ 5.49 164 90 1.6 600 920 91 100 1.0 600 1200
73
AS 20_ 6.46 139 90 1.4 600 1030 77 100 0.85 600 1340
AS 20_ 7.75 116 90 1.2 600 1160 65 100 0.71 600 1490
AS 20_ 8.57 105 90 1.0 600 1240 58 100 0.64 600 1580
AS 20_ 9.92 91 90 0.90 600 1290 50 100 0.55 600 1650
AS 20_ 11.67 77 90 0.76 600 1420 43 100 0.47 600 1810
AS 20_ 14.0 64 90 0.64 600 1580 36 100 0.39 600 2000
AS 20_ 15.48 58 90 0.58 600 1670 32 100 0.36 600 2100
AS 20_ 18.01 50 90 0.50 600 1740 27.8 100 0.31 600 2200
AS 20_ 21.19 42 90 0.42 600 1900 23.6 100 0.26 600 2400
AS 20_ 25.43 35 90 0.35 600 2090 19.7 100 0.22 600 2620
AS 20_ 28.13 32 90 0.32 600 2190 17.8 100 0.20 600 2750
AS 20_ 31.71 28.4 90 0.28 600 2270 15.8 100 0.17 600 2800
AS 20_ 37.31 24.1 90 0.24 600 2460 13.4 100 0.15 600 2800
AS 20_ 44.77 20.1 90 0.20 600 2680 11.2 100 0.12 600 2800
AS 20_ 49.52 18.2 90 0.18 600 2800 10.1 100 0.11 600 2800
AS 20 D_ 58.1 15.5 100 0.17 330 2800 8.6 100 0.10 330 2800
AS 20 D_ 64.3 14.0 100 0.16 330 2800 7.8 100 0.09 330 2800
AS 20 D_ 69.2 13.0 100 0.15 330 2800 7.2 100 0.08 330 2800
AS 20 D_ 81.4 11.1 100 0.12 330 2800 6.1 100 0.07 330 2800
AS 20 D_ 97.7 9.2 100 0.10 330 2800 5.1 100 0.06 330 2800
AS 20 D_ 108.1 8.3 100 0.09 330 2800 4.6 100 0.05 330 2800
AS 20 D_ 120.1 7.5 100 0.08 330 2800 4.2 100 0.05 330 2800
AS 20 D_ 141.3 6.4 100 0.07 330 2800 3.5 100 0.04 330 2800
AS 20 D_ 169.5 5.3 100 0.06 330 2800 2.9 100 0.03 330 2800
AS 20 D_ 187.5 4.8 100 0.05 330 2800 2.7 100 0.03 330 2800
