CCS800 | Service manual | Chapter 10 | Trunk cable interconnections en | 45
Bosch Security Systems | 2005-01| 3922 880 21112
10.2 LBB 3316/00 – CCS800 extension cable and connectors
CCS800 trunk cable Bosch type nr Bosch code nr.
Installation cable 6mm Ø,
100 meter with set of 5
male and female
connectors
LBB 3316/00 8900 331 60005
CCS800 trunk cable
connectors
Hirschmann
type nr.
Hirschmann
code nr.
Hirschmann model
Male:
7-Pol. DIN Cable-Plug
MAS70S
930 356-500 (black)
930 356-517 (grey)
Female:
7-Pol. DIN Cable-Socket
MAK70S 930 388-517 (grey)
Attenuator SLB code nr Diagram Attenuator model
Microphone input
attenuation 50dB.
XLR microphone socket
X9.
3938 042 00031
