Bosch CCS800 - 12.3 Delegate and Chairman Unit Spare Parts

CCS800 | Service manual | Chapter 12 | Spare parts en | 48
Bosch Security Systems | 2005-01| 3922 880 21112
12.2.4 LBB 3310/x0 CPSU – Printed board spare parts
Pos Nr Description Service Code
B1 LED green 5322 130 11298
R199 Trim potmeter 1K lin 10% - gain mic 5322 101 11902
R200 Trim potmeter 50K lin 10% - gain rec 5322 101 11901
R201 Potmeter 10K log 20% - volume 5322 101 11763
S1, S4 Slide switch 2-pos. 5322 277 21434
S2 Rotary switch binary 5322 273 10352
S3 Rotary switch 11-pos 5322 273 10353
T1 Output transformer 0,1W 5322 146 11015
X2, X3 Audio socket bus DIN 7p 5322 267 50547
X8 Headphone socket 5322 265 11327
X9 XLR socket 3p 5322 265 11325
X11 4 pin jack assembly 5322 265 11326
X12 6 pin jack assembly 5322 265 11324
SMD parts
D1 Vreg 15V MC78l15acdr2 9338 856 30668
D2 Volt Prec Ref TI431bcdr2 9322 097 54668
D3 Vreg Adj 100mA LM337lm 9339 800 00668
F1 Fuse Resettable (Ptc) 2422 549 43711
N1-N2,N5-
N7
Op Quad MC33179D So14 9322 070 18668
N3-N4 Comparator Quad LM339D 9336 559 60623
V1-V3 Diode BAV99 (A7) Sot23 9332 153 70215
V32-V33,
V35-V58
BZX284 C33 Zp Sod110 9340 388 00115
V34,V59 BZX284 C3V3 Yr Sod110 9340 385 60115
12.3 Delegate- and chairman unit spare parts list
12.3.1 LBB 3330/x0 Delegate unit – Mechanical spare parts
LBB 3331/x0 Chairman unit – Mechanical spare parts
Pos Nr Description Service Code
5 Thumbwheel 5322 410 11108
6 Ring for thumbwheel 5322 532 12783
7 Upper housing delegate ccs800 incl. mic. Knob – Philips 5322 442 01417
7 Upper housing delegate ccs800 incl. mic. Knob – Bosch 3922 156 27800
7 Upper housing chairman ccs800 incl. mic. & prior. knob – Philips 5322 442 01418
7 Upper housing chairman ccs800 incl. mic. & prior. knob – Bosch 3922 156 27810
15 Loudspeaker PF302 (3 Inch) 5322 240 30708
16 Loudspeaker spring 5322 492 11411
17 Loudspeaker cable assembly (without sleeve) 5322 320 11887
22 Washer 19mm 5322 532 13026
23 Hex. Nut M18x0.75mm 5322 505 11265
24 Retaining ring 19mm 5322 532 13027
29 Clamping bracket 5322 401 11692
31 Foot plastic transparent adhesive (older series) 5322 462 41686
31 Foot rubber, black 3922 150 03930
33 Sealing ring for headphone socket 5322 532 12784
