CCS800 | Service manual | Chapter 12 | Spare parts en | 49
Bosch Security Systems | 2005-01| 3922 880 21112
37 Damping foam disc for loudspeaker 5322 466 11983
38 Trunk cable assembly male 7p CCS800 – Bosch 5322 320 12374
12.3.2 LBB 3330/x0 Delegate unit – Service assemblies
LBB 3331/x0 Chairman unit – Service assemblies
Pos Nr Description Service Code
1 Delegate board CCS800 – Philips 5322 214 12778
1
Delegate board CCS800 – Bosch (R)
3922 156 20200
1 Chairman board CCS800 - Philips 5322 214 12779
1
Chairman board CCS800 – Bosch (R)
3922 156 20240
20 Microphone CCS800 assembly short 5322 242 10918
20 Microphone CCS800 assembly long 5322 242 10919
12.3.3 LBB 3330/x0 Delegate unit – Printed boards spare parts
LBB 3331/x0 Chairman unit– Printed boards spare parts
Pos Nr Description Service Code
R54 Potmeter 10k volume headphone 5322 101 11763
R72 Trim potmeter 10k microphone 5322 101 10714
S1, S2 Push switch micro and prio 5322 276 13533
S37, S42 Slide switch 2-pos. 5322 277 11793
T5 Output transformer 0,1W 5322 146 11015
X6, X7 Headphone socket 5322 267 31808
X11 Audio con socket 7-p DIN 5322 267 50547
SMD parts
D1-D6 BZX84 C33 Y12 Sot23 9333 883 40215
D70 LED Hsmh-C650 Red 9322 080 60685
D7-D8-D87 Diode BAV99 (A7) Sot23 9332 153 70215
IC10 Vreg 15V MC78I15acdr2 9338 856 30668
IC15 Vreg 5V LM78l05acm-x So8 9339 773 50668
IC20,IC50,IC
80
Op Quad MC33179D So14 9322 070 18668
IC30-IC31 Comparator Quad LM339D 9336 559 60623
R9 Fuse Resettable (PTC) 2422 549 43711
12.4 Microphone head spare parts
Pos Nr Description Service Code
1 Microphone cap 5322 462 10804
2 Microphone capsule EM135M 2422 549 44537
3 Suspension, rubber 3922 150 03761
7 Capacitor 1nF 50V Smd 2% 0805 2238 861 14102
