CCS800 | Service manual | Chapter 12 | Spare parts en | 47
Bosch Security Systems | 2005-01| 3922 880 21112
12 Spare parts
12.1.1 Ordering spare parts
Spare parts can be ordered with there unique Service code number through the local Bosch representative.
Contact the local Bosch representative in case of questions/ remarks about e.g. availability, ordering/ supply procedures,
prices, complaints, replacements, etc.
Please note that some parts are delivered only in standard quantities of 10, 20, 50 or 100 pieces depending on their price.
12.2 CPSU spare parts list
• Pos Nrs. Spare part tables.
The listed numbers are corresponding with numbers in the exploded views, board layouts and circuit diagrams.
• Parts for central repair
Items in the spare part lists indicated with a ‘(R)’ behind the service code is subject for ‘Carry In’ central repair
(see chapter 1.4 and 1.5).
12.2.1 LBB 3310/x0 CPSU – Mechanical spare parts
Pos Nr Description Service Code
1 Upper housing part CPSU – Philips 5322 441 12204
1 Upper housing part CPSU – Bosch 3922 156 28120
3 Knob control gray – Philips 5322 410 11877
3 Knob control silver – Bosch 3922 150 05100
4 Knob on/off green – Philips 5322 410 11878
4 Knob on/off silver – Bosch 3922 150 05110
6 Power switch + cable assembly 5322 276 13983
9 Loudspeaker PF302 (3 Inch) 5322 240 30708
10 Loudspeaker spring 5322 492 11411
12 Appliance inlet 2p+e 10a 5322 265 11323
16PH Locking card spacer – Philips CPSU only 5322 532 13025
17 Ring for knob 5322 532 12783
20 Flat cable assembly 2x10p 240mm 5322 320 12373
23 Foot bottom rubber, black 5322 462 11084
29 Mains cord 2mtr, EUR version 5322 321 11422
29 Mains cord 2mtr, USA version 5322 321 11423
Attenuator 50DB (accessory for XLR mic input) 3938 042 00031
12.2.2 LBB 3310/00 CPSU – Printed board assemblies
Pos Nr Description Service Code
13
Power supply unit 24V (R)
5322 218 11902
18
CPSU board for LBB 3310/00 – Bosch (R)
3922 156 30410
12.2.3 LBB 3310/10 CPSU – Printed board assemblies
Pos Nr Description Service Code
13
Power supply unit 24V (R)
5322 218 11902
18
CPSU board for LBB 3310/10 (R)
3922 156 28140
28
AFS board for LBB 3310/10 (R)
3922 156 28220
