D8125 | Installation and Operation Guide | 4.0 Installation
.
Bosch Security Systems B.V. | 2020.04 | F01U036298-15 21
ZN101S2
Memory of Previous Events: The D1252A
displays a memory code to annunciate events
which have taken place since the system was
last armed.
1
=
Alarm Memory
2
=
Trouble Memory
3
=
Alarm and Trouble Memory
4
=
Missing Memory
5
=
Alarm Memory and Missing
6
=
Trouble Memory and Missing
7
=
Alarm & Trouble Memory Missing
Current State of Sensor Loop
O
=
Sensor loop electrically open
or grounded
S
=
Sensor loop electrically
shorted
(blank)
=
Sensor loop electrically normal
M
=
Missing POPIT Module (POPIT
is programmed to be in the
system, but is not responding
to polling)
X
=
Extra POPIT Module (POPIT is
responding to polling, but is
not programmed to be in the
system
POPIT Expansion Point:
This is the
identification of the Module transmitting the
event (ex., point 01).
Master Zone Number:
The D9112G master
zone number assigned to the POPIT (ex. master
zone 100).
Zone: This identifies the display as a POPIT
status display.
Figure 5: Explanation of POPIT Display
