1.0 Introduction
This guide covers installation of the D8125 POPEX Module for use with the D9127U/T POPITs on the new
G Series control panels (B9512G, B9512G-E, B8512G, B8512G-E), G Series control panels (D9412GV4,
D7412GV4, D7212GV4, D9412GV3, D7412GV3, D7212GV3, D9412GV2, D7412GV2, D7212GV2, D9412G,
D7412G, D7212G), and D9124 control panel.
The B600 Retrofit (ZONEX) module is
required to use the D8125 on the
B9512G, B9512G-E, B8512G, and
B8512G-E control panels.
Refer to the installation and programming literature for the control panel for a detailed description of the
ZONEX (Zone Expansion) system, including the D8125 POPEX module.
1.1 Specifications
Operating Voltage
D8125 POPEX 10.2 VDC to 14 VDC supplied by AUX POWER
Current
D8125 POPEX 50 mA per POPEX Module + POPIT current
D9127U/T
POPIT
0.5 mA per POPIT Module
Operating Temperature
+32°F to +122°F (0°C to +50°C), @ 86% Relative Humidity
Resistance
Maximum resistance between the POPEX Module and any POPIT is 90
Maximum resistance on the POPIT Loop is 1000
Sensor Loop Response
Time
Approximately 1 second.
POPIT sensor loops are supervised with a 33 kEnd-Of-Line resistor
Low Condition Voltages
Open:
12 VDC
Normal: 6 VDC
Shorted: 0 VDC
The B9512G, B9512G-E, B8512G, B8512G-E, D9412G, D7412G, and
D7212G/GV2/GV3/GV4 control panels indicate SERVC GND FAULT on
keypads when a ground fault condition is present on the loop input. All
other 9000 Series Control Panels respond to a grounded loop as an
open condition.
Dimensions (H x W x D)
D8125 module: 0.75 in. x 2.88 in. x 5.0 in. (19 mm x 73 mm x 12.7
cm)
D9127U/T
enclosure:
0.94 in. x 1.5 in. x 3.2 in (24 mm x 38 mm x 81 mm)
