Bosch DS7400XiV4-EXP Reference Guide

DS7400XiV4-EXP | Wireless Reference Guide | 3.0 Adding Wireless Sensors/Contacts EN | 11
Bosch Security Systems | 6/05 | 4998154962B
Table 10: Address 0483 to 0538, Data Digit 2
(Even-Numbered Zones)
Select Option Value
RF Sensors/Contacts
0
RF Keyfobs
5
Table 11: Address 0483 to 0538, Zone-to-Address Cross Reference
Zones Address Zones Address Zones Address
Zones 137 & 138 0483 Zones 175 & 176 0502 Zones 213 & 214 0521
Zones 139 & 140 0484 Zones 177 & 178 0503 Zones 215 & 216 0522
Zones 141 & 142 0485 Zones 179 & 180 0504 Zones 217 & 218 0523
Zones 143 & 144 0486 Zones 181 & 182 0505 Zones 219 & 220 0524
Zones 145 & 146 0487 Zones 183 & 184 0506 Zones 221 & 222 0525
Zones 147 & 148 0488 Zones 185 & 186 0507 Zones 223 & 224 0526
Zones 149 & 150 0489 Zones 187 & 188 0508 Zones 225 & 226 0527
Zones 151 & 152 0490 Zones 189 & 190 0509 Zones 227 & 228 0528
Zones 153 & 154 0491 Zones 191 & 192 0510 Zones 229 & 230 0529
Zones 155 & 156 0492 Zones 193 & 194 0511 Zones 231 & 232 0530
Zones 157 & 158 0493 Zones 195 & 196 0512 Zones 233 & 234 0531
Zones 159 & 160 0494 Zones 197 & 198 0513 Zones 235 & 236 0532
Zones 161 & 162 0495 Zones 199 & 200 0514 Zones 237 & 238 0533
Zones 163 & 164 0496 Zones 201 & 202 0515 Zones 239 & 240 0534
Zones 165 & 166 0497 Zones 203 & 204 0516 Zones 241 & 242 0535
Zones 167 & 168 0498 Zones 205 & 206 0517 Zones 243 & 244 0536
Zones 169 & 170 0499 Zones 207 & 208 0518 Zones 245 & 246 0537
Zones 171 & 172 0500 Zones 209 & 210 0519 Zones 247 & 248 0538
Zones 173 & 174 0501 Zones 211 & 212 0520
NOTE: When using premises RF: 1) Zones 129 through 136 are reserved, and 2) Zones 137 through 248 are available as RF
zones only. Wired zones cannot reside in zones 137 through 248 when using RF.
3.4 Assign an Area (Partition) to the Zone
Each zone is assigned to an area. By default, all zones are assigned to Area 1.
The area assignment for odd numbered zones is programmed in the first data digit of these addresses. The area
assignment for even numbered zones is programmed in the second data digit of these addresses.
For example, to assign Zone 137 to Area 1 and Zone 138 to Area 2, program Address 0355 as 01.
Refer to Table 13 to determine which zones apply to each program address.
• Addresses: 0355 to 0410
• Data Digits:
• Data Digit 1: ____ (refer to Table 12; default = 0; applies to odd-numbered zones)
• Data Digit 2: ____ (refer to Table 12; default = 0; applies to even-numbered zones)
• Selections: 0 to 7
