DS7400XiV4-EXP | Wireless Reference Guide | 3.0 Adding Wireless Sensors/Contacts EN | 8
Bosch Security Systems | 6/05 | 4998154962B
Table 4: Zone Function Programming (Address 0001 to 0030, Data Digit 1)
Selections for Data Digit 1
Select Options 0 1 2 3 4 5 6 7 8 9 *0 *1 *2 *3 *4 *5
Invisible Alarm
•
• •
Silent Alarm
•
• •
Steady Alarm Output
•
• •
Pulsing Alarm Output
•
• •
Alarm on Short
• • • •
• • • •
Alarm on Open
• • • •
• • • •
Trouble on Open
1
• • • •
Trouble on Short
• • • •
1
Only when disarmed. When armed, this becomes Alarm on Open or Short for non-24-hour zones.
NOTE: Multiplex contacts should not be programmed for Trouble on Open.
Table 5: Zone Function Programming (Address 0001 to 0030, Data Digit 2)
Select Options Value Select Options Value
Interior Delayed 0 Day Monitor 8
Perimeter Instant 1
Keyswitch
2
9
24-Hour 2 Fire Zone with Verification *0
Entry/Exit Delay #1 3 Fire Zone without Verification *1
Entry/Exit Delay #2 4 Waterflow *2
Interior Entry/Exit Follower 5 Supervisory *3
Interior Home/Away 6 Entry/Exit Delay Cancel 1 *4
Interior Instant 7 Entry/Exit Delay Cancel 2 *5
2
If Data Digit 2 = 9 (keyswitch), refer to Table 6 to determine the value for Data Digit 1.
Table 6: Address 0001 to 0030, Data Digit 1, if
Data Digit 2 = 9
Select Options Value
Single Partition – No Force Arm 0
Single Partition – Can Force Arm 1
All Partitions – No Force Arm 2
All Partitions – Can Force Arm 3
