5.5 Program the Wireless Keyfob Panic Function (Optional)
The Panic function only operates if programmed in the control panel. Programming Address 3148 (“C” key) allows
you to disable or enable the Panic key on the keyfob for silent, pulsed, or steady alarm. Refer to Emergency Key
Programming: Program Addresses 3147-3148 in the DS7400Xi-EXP Reference Guide (P/N: 4998154963) for more
information.
If the control panel is set for Commercial Fire Mode, the values for the Panic Key might be forced to
different values. For more information, refer to Commercial Fire Mode Programming: Program Address
2733 in the DS7400Xi-EXP Reference Guide (P/N: 4998154963).
• Address: 3148
• Data Digit:
• Address 3148, Data Digit 1: ____ (refer to Table 33; default = 0)
• Address 3148, Data Digit 2: Must be 0
• Default: 0
• Selections: 0 to 3
Table 33: Panic Key C Selections (Address 3148 Data Digit 1)
Select Option Value
Panic Key Disabled
0
Panic Key = Silent Alarm 1
Panic Key = Steady Alarm 2
Panic Key = Pulsed Alarm 3
5.6 Program On-Board Outputs for the RF3334/RF3334E Keyfob (Optional)
The RF3334/RF3334E Keyfob has two key outputs which you can program to drive the control panel’s on-board
outputs. Use either key to drive any of the three on-board outputs, or any of the 24 custom programmable
outputs.
The operation of the Option key is the same on all keypads and keyfobs if they are assigned to the same area.
• Addresses: 2734 to 2736
• Data Digits:
• Data Digit 1: Must = *0 for wireless keyfob outputs (refer to Table 35 for default values)
• Data Digit 2: ____ (refer to Table 34 for options; refer to Table 35 for default values)
• Selections: 0 to 4
Table 34: Programming On-Board Keyfob
Outputs (Address 2734 to 2736,
Data Digit 2 When Data Digit 1 = *0)
Options RF3334/RF3334E Value
Disabled 0
Momentary Option Key 1
Toggle Option Key 2
Momentary Auxiliary Key 3
Toggle Auxiliary Key 4
Table 35: Address 2734 to 2736 Defaults
Output Address Default
Alarm 2734 6 3
Programmable Output 1 2735 3 3
Programmable Output 2 2736 2 3
